  • The Baron

    The Baron

    This is my second entry in the End of Days Fuzz Challenge! The idea was to build a circuit similar to the Proco Rat replacing the LM308 with the LM386. The LM308 is a single op-amp the LM386 is an audio amplifier. The chips are similar but also very different. LM386 The LM386 is similar…

  • 1981 Inventions DRV clone.

    1981 Inventions DRV clone.

    Here’s a PedalPCB Informant. This is mostly the Rat circuit with a few changes. The biggest change is the addition of a charge pump. The charge pump provides a +9 and -9 volts power for the circuit to run off. Effectively this doubles the voltage. I have some reservations about the power supply. The clipping…

  • D*A*M Ezekiel clone

    D*A*M Ezekiel clone. I guess this is a Rat with a blend knot and some diode options.

  • Zeke Bass Distortion – OSH Park

    Zeke Bass Distortion – OSH Park

    This Zeke Bass Distortion is a clone of the D*A*M Ezekiel 25:17 Bass distortion. The PCB came from OSH Park. This worked out well. The board is pretty big so soldering parts is easy. The rotary switch and pots are all mounted on the board, which makes assembly easy, this is a good PCB. There…
